EXCLUSIVELY FROM AHLBORN-GALANTI
Unparalleled Digital Pipe Organ Sound
DRAKE™ Technology
5 Interactive Stop Lists™
5 Interactive Channellings™
Interactive Programmer™ (wireless remote)
Additional Stops (selectable on each division)
Programmable Digital Acoustics™
 Windchest Layouts™
3-D Chamber Layouts™
Auto Pipe Tracking™
SPECIFICATION
90 Speaking Stops
458 Independently Voiceable Stops
132 Stop Units
 VOICING AND FINISHING
Note-by-Note Parameters
Level
Scaling
Release
Harmonics
Pitch
Ensemble
Wind Pressure
Stop-by-Stop Windchest Layoutsª
Adjustable Tremulants
 COMBINATION ACTION
25 General Pistons
8 Divisional Pistons
20 Memory Levels
Memory Level Up Piston
Memory Level Down Piston
Set Piston
General Cancel Piston
500 Stage Piston Sequencer
Piston Sequencer Up (8 thumb and 2 toe pistons)
 Piston Sequencer Down (5 thumb pistons)
Pistons Coupled (selectable by division)
Return to Handset Registration
5 Programmable 20-Step Crescendos
5 Programmable Tuttis
Memory Lock
Lighted Toe Pistons
REVERSIBLE PISTONS
Great to Pedal (thumb and toe)
Swell to Pedal (thumb and toe)
Choir/Positiv to Pedal (thumb and toe)
Solo/Bombarde to Pedal (thumb and toe)
Swell to Great (thumb)
Swell to Choir (thumb)
 Solo/Bombarde to Swell (thumb)
Sostenuto (thumb and toe)
Contre Bombarde 32 (toe)
Untersatz 32 (toe)
Sub Principal 32 (toe)
Tutti (thumb and toe)
Pipes (thumb)
Digital (thumb)
Pistons Coupled (thumb)
Automatic Pedal (thumb)
Full Tremulant (thumb)
Solo Coupler (thumb)
All Swells to Swell (thumb)
SPEAKER AND AMPLIFICATION SYSTEMS
Custom Designed External Speaker and Amplification System
18 Independent External Output Channels
Independent 5 Band Equalizer for each Output Channel Pair
Headphone Jack
AUX IN 1 Stereo MIC/Line with L/R Sensitivity Controls
AUX IN 2 Stereo
|
ELEGANT AND METICULOUSLY
CRAFTED CONSOLES
Detailed Molding for Console and Bench
Wooden Roll-Top with Key Lock
Lighted Music Rack
Beveled Bench with Music Storage Shelf
Lighted Pedalboard
Wooden Pedal Keys
Tracker Touch Keyboards
Full Pipe Organ Compatibility
 EXPRESSION
Stop-by-Stop Selectable Expression
Swell Expression Pedal
Choir/Positiv Expression Pedal
Solo/Bombarde Expression Pedal
Expression Pedal Range Adjustable for Each Division
Selectable Expression Mode (mechanical or 8 stage)
Great and Pedal Volume Sliders
 Programmable Great Enclosed
Programmable Pedal Enclosed
All Swells to Swell
FULL MIDI IMPLEMENTATION
Velocity-Sensitive Keyboards
MIDI Commands Programmable on General and Divisional Pistons
Programmable MIDI Channels, IN and OUT, for MIDI 1
Programmable MIDI Channels, IN and OUT, for MIDI 2
Programmable PIPE MIDI Channels
MIDI 1 IN, OUT and THRU
MIDI 2 IN, OUT and THRU
MIDI IN Filters for MIDI 1 and MIDI 2
MIDI OUT Filters for MIDI 1 and MIDI 2
MIDI Sustain (toe piston)
 ADDITIONAL FEATURES
Selectable Tracker Response
Selectable Manual Assignments
Performance Sequencer
Metronome
Disk Drive
Digital Clock with Timer
Selectable Historic Temperaments
Programmable Temperaments
12 Step Transposer +/- 6 Half Steps
Computer Serial Port
Extensive Built-In Pipe Organ Sound Library
Built-In Instrumental Sound Library
DIMENSIONS
Built to American Guild of Organists Standards
Size (as shown): 80" wide, 58" high, 46" deep (58" with pedalboard)
SAFETY AND COMPLIANCE
ETL Approved (meets UL-469 standards)
Complies with Part 15 of the FCC rules
 WARRANTY
10 Year Limited Parts Warranty
CUSTOM CONFIGURATION
Console Styling and Finishes
Specifications
Keyboards
 Drawknobs
Engravings
Adjustable Bench (optional)
Backrest for Bench (optional)
Bench Risers (optional)
Console Dolly (optional)
|
